Description
TECHNICAL SPECIFICATIONS
Features
| Motor: AC / DC | No / Yes |
| Drive System: Belt / Direct | Yes / No |
| Bearing: Ceramic / Metal | No / Yes |
| Operation: Automatic / Manual | Yes / No |
| Speed: 33-1/3 & 45 RPM | Yes / Yes |
| Wow & flutter | 0.15 % (WRMS) |
| Phono EQ built in (switchable) | Yes |
| Stylus (MM / MC) | Yes / No |
| Stylus version | DSN-82 |
| Belt Rubber Silicon | Yes / No |
Specifications
| Rated Output | 2.5 mV / 1 kHz |
| Frequency Range | 20 Hz – 20 kHz |
| S/N ratio | No |
| Rated Output Phono EQ | EQ 150 mV / 1 kHz |
General
| Maximum Dimensions (W x D x H) in inches | 14.2 x 14.1 x 3.8 |
| Weight in LBS | 6.2 |
