Description
ASW608
Size-defying bass
Technical specfications
Features
Volume level – line in
Volume level – speaker in
Low-pass filter frequency
Low-pass filter bypass (line in only)
Bass extension
Bass roll-off alignment
Auto sense on / standby
Phase switch
Model
ASW608
Drive unit
200mm (8in) paper / Aramid fiber cone long-throw
Power output
200W
Rated power consumption
40W
Standby power consumption
0.5W
Input impedance
33kΩ
Signal / noise
>90dB
Inputs
Stereo line in (RCA Phono)
Speaker in (Binding post)
12v trigger (3.5mm jack)
Dimensions
Height: 260mm (10.2in) not including feet or spikes
272mm (10.7in) including feet
288mm (11.3in) including spikes
Width: 260mm (10.2in)
Depth: 305mm (11.99in) not including grilles
330mm (13in) including grilles and controls
Net weight
8.85kg (19.5lb)
Cabinet finishes
Black
White
Grille finishes
Black
Grey
