All About The Intuition
Intuitive and easy-to-use, the ACE is Roon Ready and allows the playback of all major file formats, including DSD, and MQA (via local files and TIDAL Master files).
Complete and Simple
Our award-winning ACE is the complete all-in-one music system. Simply hook up a pair of speakers, connect to the internet and sit back and enjoy your music.
Featuring the world-renowned MOON sonic signature of visceral tight bass, transparent midrange, precise natural highs and lifelike sound, the ACE will always deliver an unforgettable performance.
Don’t forget vinyl!
Turntable owners have not been forgotten as the moving magnet phono stage allows the ACE to bring the best out of any vinyl record.
- 3 line-level inputs including a front-mounted 1/8” mini-jack for personal media players.
- Headphone output on 1/4” jack located on the front panel.
- Seamless integration with our MiND app.
- 8 digital inputs include USB (hi-res audio), SPDIF (2), Optical (2), Qualcomm aptX audio for Bluetooth®, WiFi and Ethernet.
- OLED type screen which provides more detailed information.
- Simple MiND setup via on-board software menu.
- Moving magnet phono preamplifier input.
- Analog inputs are configurable to “pass-through” mode, which bypasses the gain stage to accommodate components like a home-theater processor, whose own volume control is used.
For MOON ACE equipped with MiND 2:
Output Power at 8Ω50 W per channel
Input Sensitivity370 mV – 3.0 V RMS
Input Impedance22,1 kΩ
Signal-to-noise Ratio100 dB @ full power
Frequency response (full range)10 Hz – 80 kHz +0/-3 dB
THD (20Hz – 20kHz @ 1 W / 50 W)0.02 % / 0.02 %
PCM Bit-depth range / sampling rates16 – 32 bits / 44.1 – 384 kHz
DSD sample ratesDSD64, DSD128 & DSD256
Shipping weight24 lb / 11 kg
Dimensions (width x height x depth)16.9 x 3.5 x 14.4 in
42.9 x 8.9 x 36.6 cm
The following accessories should be included inside the box with your All-in-One:
- AC power cable
- ‘CRM-3’ remote control with two ‘CR-2032’ batteries
- ‘SimLink™’ cable
- Wi-Fi antenna
- 1 spare fast-blow fuse
- Owner’s manual
- Quick reference guide
- Warranty and product registration information (USA and Canada only)
