| Camera |
|---|
| Image Sensor | 1/1.8" progressive scan CMOS
|
| Max. Resolution | 2560 × 1440
|
| Min. Illumination | Color: 0.005 Lux @ (F1.5, AGC ON), B/W: 0.001 Lux@(F1.5, AGC ON), 0 Lux with IR
|
| Shutter Speed | 1/1 s to 1/30000 s
|
| Day & Night | IR cut filter
|
| Zoom | 32x optical, 16x digital
|
| Slow Shutter | Yes
|
| DORI | Detect (25px/m): 2046.9 m,Observe (63px/m): 812.3 m,Recognize (125px/m): 409.4 m,Identify (250px/m): 204.7 m |
| Lens |
|---|
| Focal Length | 5.9 mm to 188.8 mm
|
| FOV | Horizontal field of view: 50.8° to 2.6° (wide-tele),
Vertical field of view: 29.4° to 1.5° (wide-tele),
Diagonal field of view:57.4° to 3° (wide-tele)
|
| Focus | Auto,semi-auto,manual
|
| Aperture | Max. F1.5
|
| Zoom Speed |
Approx. 4.8 s |
| Illuminator |
|---|
| Supplement Light Type | IR
|
| Supplement Light Range |
IR Distance: up to 200 m |
| PTZ |
|---|
| Movement Range (Pan) | 360°
|
| Movement Range (Tilt) | -15° to 90° (auto flip)
|
| Pan Speed | Pan speed: configurable from 0.1° to 160°/s; preset speed: 240°/s
|
| Tilt Speed | Tilt speed: configurable from 0.1° to 120°/s, preset speed 200°/s
|
| Proportional Pan | Yes
|
| Presets | 300
|
| Preset Freezing | Yes
|
| Patrol Scan | 8 patrols, up to 32 presets for each patrol
|
| Pattern Scan | 4 pattern scans
|
| Park Action | Preset, pattern scan, auto scan, tilt scan, random scan, frame scan, panorama scan
|
| 3D Positioning | Yes
|
| PTZ Status Display | Yes
|
| Scheduled Task |
Preset, pattern scan, patrol scan, auto scan, tilt scan, random scan, frame scan, panorama scan, dome reboot, dome adjust, aux output
|
| Power-Off Memory |
Yes |
| Audio |
|---|
| Audio Compression | G.711alaw, G.711ulaw, G.722.1, G.726, MP2L2, AAC, PCM
|
| Audio Bit Rate | 64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32-192 Kbps (MP2L2)/16-64 Kbps (AAC)
|
| Audio Sampling Rate | 8 kHz/16 kHz/32 kHz/48 kHz
|
| Environment Noise Filtering |
Yes |
| Network |
|---|
| Protocols | IPv4/IPv6, HTTP, HTTPS, 802.1x, QoS, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour
|
| Simultaneous Live View | Up to 20 channels
|
| API | Open Network Video Interface (Version 19.12, Profile S, Profile G, Profile T), ISAPI, SDK, ISUP |
| User/Host |
Up to 32 users, 3 user levels: administrator, operator, and user |
| Security | Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, RTP/RTSP over HTTPS, control timeout settings, security audit log, TLS 1.2, TLS 1.3, host authentication (MAC address)
|
| Network Storage | NAS (NFS, SMB/CIFS), auto network replenishment (ANR)
|
| Client | iVMS-4200, HikCentral Pro, Hik-Connect
|
| Web Browser |
IE11, Chrome 57+, Firefox 52+, Safari 11+ |
| Image |
|---|
| Image Settings | Saturation, brightness, contrast, sharpness, gain, and white balance adjustable by client software or web browser
|
| Day/Night Switch | Day, Night, Auto, Schedule
|
| Wide Dynamic Range (WDR) | 120 dB
|
| SNR | > 52 dB
|
| Defog | Digital defog
|
| Image Stabilization | EIS
|
| Image Enhancement | BLC, HLC, 3D DNR
|
| Privacy Mask | 24 programmable polygon privacy masks, mask color or mosaic configurable
|
| Regional Focus | Yes
|
| Regional Exposure |
Yes |
| Interface |
|---|
| Ethernet Interface | 1 RJ45 10M/100M self-adaptive Ethernet port
|
| On-Board Storage | Built-in memory card slot, support microSD/SDHC/SDXC card, up to 256 GB
|
| Built-In Speaker | 1 built-in speaker with effective distance reaching max. 30 meters
|
| Audio | 1 input (line in), max. input amplitude: 2-2.4 vpp, input impedance: 1 kΩ ± 10%; 1 output (line out), line level, output impedance: 600 Ω
|
| Alarm |
2 inputs, 1 output
|
| Reset |
Yes |
| Event |
|---|
| Basic Event | Motion detection, video tampering alarm, exception, alarm input and output
|
| Smart Event | Line crossing detection, intrusion detection, region entrance detection, region exiting detection, unattended baggage detection, object removal detection, audio exception detection
|
| Linkage | Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger alarm output, trigger recording, audible warning, white light flashing, and PTZ actions (such as preset, patrol scan, pattern scan)
|
| Deep Learning Function |
|---|
| Face Capture | Detects up to 5 faces simultaneously.
Supports detecting, capturing, grading, selecting of face in motion, and output the best face picture of the face
|
| Perimeter Protection | Line crossing, intrusion, region entrance, region exiting,Support alarm triggering by specified target types (human and vehicle) |
| General |
|---|
| Power | 24 VAC, max. 42 W (including max. 18 W for IR and max. 10 W for heater);Hi-PoE
|
| Dimension | Ø 220 mm × 363.3 mm (Ø 8.66" × 13.91")
|
| Weight | Approx. 5 kg (11.03 lb.)
|
| Material | ADC12
|
| Operating Condition | -30 °C to 65 °C (-22 °F to 149 °F). Humidity 90% or less (non-condensing)
|
| Demist |
Yes |
| Approval |
|---|
| EMC | FCC SDoC (47 CFR Part 15, Subpart B);
CE-EMC (EN 55032: 2015, EN 61000-3-2: 2019,
EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014);
RCM (AS/NZS CISPR 32: 2015);
IC VoC (ICES-003: Issue 6, 2019);
KC (KN 32: 2015, KN 35: 2015) |
| Safety | UL (UL 62368-1);CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014);CE-LVD (EN 62368-1:2014+A11:2017);BIS (IS 13252(Part 1):2010+A1:2013+A2:2015);
LOA (SANS IEC60950-1) |
| Specifications |
|---|
| Environment |
CE-RoHS (2011/65/EU); WEEE (2012/19/EU);
|
| Environment | Reach (Regulation (EC) No 1907/2006) |
| Protection |
IP66 (IEC 60529-2013), IK10 (excluding glass window), TVS 6000V lightning protection, surge protection and voltage transient protection |
