Control4 4-Zone Matrix Amplifier - C4-8AMP1
Literature
The 4-Zone Matrix Amplifier amplifies and distributes audio from any four sources, including digital, to any four zones.
Control4 matrix amplifiers provide high-quality sound to four or eight audio zones from distinct sources. Regardless of the size of your home or project, you’ll enjoy a powerful, multi-room music solution that’s fully integrated into your Control4 system. Both amplifiers offer full matrix switching, advanced parametric equalizer, independent input gain control and volume limiting capabilities.
- The 4-zone matrix amplifier lets you enjoy 60W of high-quality sound from 4 analog and 2 digital input sources in 4-speaker output zones.
- The 4-zone matrix amplifier supports Auto Power-Save mode—when it’s not in use, it drops into energy-conservation mode using just 2 watts of power.
- Tweak the sound on any speakers using the parametric equalizer. The Control4 Equalizer app lets you view and adjust a range of settings from on-screen and touch-screen devices.
| Specifications | |
|---|---|
| Analog Input Sources | 4 |
| Digital Input Sources | 2 |
| Speaker Output Zones | 4 |
| Line Level Output Zones | 0 |
| Rated Wattage per Channel | 60 @ 8 ohms, 120 @ 4 ohms |
| Frequency Response | 19 Hz – 20 kHz, +/-.5dB @ 8 ohms, +/- .2dB @ 4ohms |
| Signal-to-Noise Ratio | >95 dB |
| THD | <0.02% – 20 Hz – 20 kHz |
| Network Connectivity | 10/100 BaseT Ethernet |
| Tone Controls | Bass, Treble, 5-band parametric EQ |
| Display | Backlit Monochrome LCD |
| Full Matrix Switching | Yes |
| Independent Gain Control per Zone | Yes |
| Rack Mount Kit | 3U Rack Mount Kit with ventilation (C4-3URMK-B), 3U Rack Mount Kit non-vented (C4-3URMK-NV-B) |
| Accessories | Banana Plug Kit (C4-BPLUG8) |
| Voltage | 120 – 240 VAC |
| Hertz | 50/60 Hz |
| Operational Temperature | 32° F – 104° F (0° C – 40° C) |
| Humidity | 5% – 95% Non-condensing |
| Storage Temperature | -4° F – 158° F (-20° C – 70° C) |
| HxWxD | 3.5” x 17” x 18” (89mm x 432mm x 457mm) |
| Weight | 18 lbs (8.16 kg) |
