Barco ClickShare C-10 Gen2 with 2 Button - R9861611USB2
Literature
Interactive wireless presentation for any meeting space
- Interactive features: touchback, annotation and blackboarding
- Increased collaboration with 2 sources on screen
- Iconic ClickShare Button(s) for employees and guests
- 100% secure, encrypted and cloud-managed
ClickShare C-10 brings interactive wireless presentation to any meeting space. Content sharing is simple, with just one click on the ClickShare Button (Windows or Mac) or the ClickShare App (laptop, mobile or tablet). Start presenting within seconds: no cables, no software to download, no training needed.
| Specifications | |
|---|---|
| Dimensions (HxWxD) | 34 mm x 135 mm x 135 mm |
| * | * depends on configuration, available in future firmware updates |
| Warranty | 1 year standard. 5 years coverage upon registering via SmartCare |
| Management and reporting | Yes |
| Network connection | LAN & WiFi |
| Local view | Yes |
| Room Dock (peripheral support) | No |
| Touch screen support & Interactivity | Yes |
| Certifications | FCC/CE |
| Anti-theft system | Kensington lock |
| Humidity | Storage: 0 to 90% relative humidity, non-condensing Operation: 0 to 85% relative humidity, non-condensing |
| Temperature range | Operating: 0°C to +40°C (+32°F to +104°F) Max: 35°C (95°F) at 3000m Storage: -20°C to +60°C (-4°F to +140°F) |
| Connections | 1x Ethernet LAN 1Gbit 1x USB-C 2.0 (front); 1x USB-A 2.0 (front) - only Gen2: 1x USB-C 3.0 (front); 1x USB-A 3.0 (front) |
| Frequency band | 2.4 GHZ and 5 GHz (DFS channels supported in select number of countries) |
| Reach | Adjustable with signal strength modulation; max. 30m (100 ft) between ClickShare Button and ClickShare Base Unit Frequency band 2.4 GHZ and 5 GHz |
| Wireless transmission protocol | IEEE 802.11 a/g/n/ac and IEEE 802.15.1 |
| Authentication protocol | WPA2-PSK in stand alone mode WPA2-PSK or IEEE 802.1X using the ClickShare Button in network integration mode |
| Noise Level | Max. 25dBA @ 0-30°C Max. 30dBA @ 30-40°C |
| Maximum sources simultaneously on screen | 2 |
| Native protocols | Airplay, Google Cast, Miracast* |
| ClickShare App | Desktop & Mobile |
| ClickShare Buttons | 1 or 2 |
| USB | 1 X USB-A, 1 X USB-C |
| Audio output | HDMI |
| Video outputs | 4K UHD (3840*2160) @ 30Hz. HDMI™ 1.4b or USB-C DisplayPort 1.2 (only Gen2) |
| System requirements | For a smooth experience with Microsoft Teams or Zoom Minimum: Intel i3 dual-core processor or AMD Ryzen 7 / 8GB RAM / OS: Windows 10 latest build or Mac OS Mojave latest build Recommended: Intel i5 4-core processor or AMD Ryzen 9 / 8GB RAM / OS: Windows 11 latest build or Mac OS latest build |
| Operating system | Windows 10 and higher macOS 11 (BigSur) and higher Android v9 and higher (ClickShare App)* iOS 12 and higher (ClickShare App)* |
| Power consumption | Operational: 5-10W, 24W Max |
| Power supply | Operational: 5-10W, 24W Max |
| Weight | 900 gr |
