Specifications
Design features
- MDCA – MOON Distortion-Cancelling Amplifier
- MOON Transistors
- Dual Mono Configuration
- M-VOL3 – 3rd Generation Improved Electronic Gain Control
- MOONLink
- 4.3’’ LCD Color Graphic Display
Specifications
-
Output Power (Stereo 8 Ω)125 W
-
Output Power (Stereo 4 Ω)250 W
-
Input Sensitivity300 mV – 6 V
-
Input Impedance22 kΩ
-
Gain37 dB
-
Frequency Response2 Hz – 90 kHz (+0 dB / –3 dB)
-
Crosstalk–109 dB
-
Signal-to-Noise Ratio109 dB
-
Total Harmonic Distortion + Noise (@ 1 W)0.008%
-
Total Harmonic Distortion + Noise (@ 125 W)0.003%
-
Intermodulation Distortion0.06%
-
Damping Factor700
-
Power Consumption (Idle)38 W
-
Power Consumption (Full Power Standby)37 W
-
Power Consumption (Low Power Standby)2.5 W
-
Shipping Weight57.5 lbs / 26 kg
-
Dimensions (width x height x depth)18.95 x 4.03 x 18.32 in
48.1 x 10.2 x 46.5 cm
